Housing | Fire retardant high temperature thermoplastic |
---|---|
94V-2 grade |
|
Insert | Brass, Nickel plated |
Voltage / Ampere (IEC) | 600V / 24A |
Voltage / Ampere (UL) | 600V / 30A |
Cross Section (mm²) | 4mm² |
AWG | 20-12 |
Temperature | |
Working | -40℃ to 100℃ |
Short Period | 140℃ |
Dimension (mm) | |
(a) Length | 116.5 |
Cross Section | |
(b) Height | 18.0 |
(c) Width | 19.0 |
(d) Fixing hole | 3.6 |
(e) Wiring hole | 3.45 |
(f) Pitch | 10 |
(g) Screw size | M3x6 |
(h) Foot width | 2.0 |
(i) Foot height | 3.8 |
Per ctn | 50x10 |
